• RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
1 1

SKU: MFC2-RHP

RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert

RHP MFC2 Four Bolt Round Cast Iron Flanged Bearing Unit and 2 inch Insert
Rs. 17,921.90 ex VAT
Rs. 17,921.90 ex VAT
Sale Sold out

In stock

Price Break
10+ Rs. 15,950.49
19+ Rs. 15,054.40
29+ Rs. 14,875.18
39+ Rs. 14,695.96
49+ Rs. 14,516.74
74+ Rs. 14,337.52
99+ Rs. 13,441.43
199+ Rs. 13,262.21
249+ Rs. 13,082.99
499+ Rs. 12,903.77
999+ Rs. 12,545.33
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing ,heavy duty full width bearing insert
Brand / Quality:
RHP - High Quality
Inside Diameter:
50.8mm = 2 inch
Style:
MFC
Pitch Circle Diameter:
136.53mm = 5.375 (5-3/8) inch
Technical
Bore 2 inch
L 6.374 inch
H 4.5 inch
J 5.375 inch
G 0.4375 inch
A1 1.562 inch
A4 0.748 inch
A5 0.252 inch
B 2.187 inch
s 0.877 inch
d1 2.709 inch
Dynamic load 43500 N
Static load 29200 N
Rec max speed 3100 rpm
Weight 3 kg
Insert <a href="advanced_search_result.php?keywords=1055-2G+insonly">1055-2G Click Here</a>
Casting group 5
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
