• RHP MFC2-3/16 Four Bolt Round Cast Iron Flanged Bearing Unit and 2-3/16 inch Insert
1 1

SKU: MFC2.3/16-RHP

RHP MFC2-3/16 Four Bolt Round Cast Iron Flanged Bearing Unit and 2-3/16 inch Insert

RHP MFC2-3/16 Four Bolt Round Cast Iron Flanged Bearing Unit and 2-3/16 inch Insert
Rs. 20,517.99 ex VAT
Rs. 20,517.99 ex VAT
Sale Sold out

In stock

Price Break
10+ Rs. 18,261.01
19+ Rs. 17,235.11
29+ Rs. 17,029.93
39+ Rs. 16,824.75
49+ Rs. 16,619.57
74+ Rs. 16,414.39
99+ Rs. 15,388.49
199+ Rs. 15,183.31
249+ Rs. 14,978.13
499+ Rs. 14,772.95
999+ Rs. 14,362.59
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing ,heavy duty full width bearing insert
Brand / Quality:
RHP - High Quality
Inside Diameter:
55.56mm = 2.187 (2-3/16) inch
Style:
MFC
Pitch Circle Diameter:
152.4mm = 6 inch
Technical
Bore 2-3/16 inch
L 7.126 inch
H 5 inch
J 6 inch
G 0.5 inch
A1 1.687 inch
A4 0.626 inch
A5 0.374 inch
B 2.562 inch
s 1.002 inch
d1 2.966 inch
Dynamic load 48000 N
Static load 33000 N
Rec max speed 2800 rpm
Weight 3.4 kg
Insert <a href="advanced_search_result.php?keywords=1060-2-3/16G+insonly">1060-2-3/16G Click Here</a>
Casting group 6
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
