SKU: HGZ40-JCS
JCS HGZ40 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 30-40mm Band Width 13mm
JCS HGZ40 Zinc Plated Steel Hi-Grip Hose Clip Adjustment Range 30-40mm Band Width 13mm
Regular price
Rs. 121.62
Regular price
Sale price
Rs. 121.62
Taxes included.
In stock
Price Break
5+
Rs. 85.13
10+
Rs. 72.97
20+
Rs. 66.89
50+
Rs. 60.81
100+
Rs. 48.65
500+
Rs. 42.57
1000+
Rs. 36.49
Description
Description
Zinc Plated Steel Hi-Grip Worm Drive Hose Clips: Used for a wide variety of domestic, automotive and industrial applications, the standard Hi-Grip hose clip is made from mild steel, electroplated, passivated and tested to EN9227. Hi-Grip general-purpose worm drive hose clips are widely regarded for their quality, durability and ability to withstand a great deal of abuse. They are manufactured to exceed BS5315, which has the highest requirements of any of the international standards and tests sealing ability, clamping force and torque.
- Brand / Quality:
- JCS - High Quality
- Width:
- 13mm
- Min Adjustment Range:
- 30mm
- Max Adjustment Range:
- 40mm
Technical
Technical
| BS No. | 40 |
|---|---|
| Adjustment Range (mm) | 30-40mm |
| Adjustment Range (inch) | 1-1/8 - 1-5/8 inch |
| A | 8mm |
| B | 15mm |
| C | 12mm |
| D | 15mm |
| E | 13mm |
| F | 0.9mm |
| Screw | 7mm A/F |
| Recommended Torque Nm | 5Nm |
| Recommended Torque lb-in | 45lb-in |
