SNR EXFE204 Metric Four Bolt Square Cast Iron Flange Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days
SNR EXFE204 Metric Four Bolt Square Cast Iron Flange Housing with 20mm Bore Eccentric Collar Insert - Allow 2-3 Days
Regular price
Rs. 2,879.14
Regular price
Sale price
Rs. 2,879.14
Taxes included.
In stock
Price Break
10+
Rs. 2,562.43
19+
Rs. 2,418.48
29+
Rs. 2,389.69
39+
Rs. 2,360.89
49+
Rs. 2,332.10
74+
Rs. 2,303.31
99+
Rs. 2,159.36
199+
Rs. 2,130.56
249+
Rs. 2,101.77
499+
Rs. 2,072.98
999+
Rs. 2,015.40
Description
Description
EXFE200 Series 4 Bolt Cast Iron Square Flange Housing: These cast iron housing units include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost-effective bearing/housing assembly, re-lubricatable, replaceable insert, grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 20mm
- Style:
- EXFE
- Bolt Hole Centres:
- 63.5mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 20mm |
| A | 29.5mm |
| A1 | 10mm |
| A2 | 45.5mm |
| B | 34mm |
| B1 | 43.5mm |
| d1 | 32.4mm |
| e | 19mm |
| J | 63.5mm |
| L | 86mm |
| N | 11.5mm |
| S | 17mm |
| G | R1/8″ |
| --- | Load rating |
| Dynamic load C | 12.8 kN |
| Static load C0 | 6.65 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 5.5 Nm |
| Mass | 0.72 kg |
