SKU: ESF211-SNR
SNR ESF211 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 55mm Bore - Allow 2-3 Days
SNR ESF211 Metric Four Bolt Square Cast Iron Flange Housing with Eccentric Collar 55mm Bore - Allow 2-3 Days
Regular price
Rs. 6,787.56
Regular price
Sale price
Rs. 6,787.56
Taxes included.
In stock
Price Break
10+
Rs. 6,040.93
19+
Rs. 5,701.55
29+
Rs. 5,633.67
39+
Rs. 5,565.80
49+
Rs. 5,497.92
74+
Rs. 5,430.05
99+
Rs. 5,090.67
199+
Rs. 5,022.79
249+
Rs. 4,954.92
499+
Rs. 4,887.04
999+
Rs. 4,751.29
Description
Description
ESF200 Series 4 Bolt Cast Iron Square Flange Housing: These cast iron housing units include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost-effective bearing/housing assembly, re-lubricatable, replaceable insert, grub screw fixing
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 55mm
- Style:
- ESF
- Bolt Hole Centres:
- 130mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 55mm |
| A | 43mm |
| A1 | 18mm |
| A2 | 61.4mm |
| B | 32.5mm |
| B1 | 48.4mm |
| d1 | 74.5mm |
| e | 25mm |
| J | 130mm |
| L | 162mm |
| N | 19mm |
| S | 12mm |
| G | M6x1 |
| --- | Load rating |
| Dynamic load C | 43.55 kN |
| Static load C0 | 29.2 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 22 Nm |
| Mass | 3.06 kg |
