SKU: BA9-SKF
SKF BA9 Single Thrust Ball Bearing 9x20x7mm
SKF BA9 Single Thrust Ball Bearing 9x20x7mm
Regular price
Rs. 4,425.61
Regular price
Sale price
Rs. 4,425.61
Taxes included.
Equivalent to: F9-20G
In stock
Price Break
10+
Rs. 3,938.79
19+
Rs. 3,717.51
29+
Rs. 3,673.26
39+
Rs. 3,629.00
49+
Rs. 3,584.74
74+
Rs. 3,540.49
99+
Rs. 3,319.21
199+
Rs. 3,274.95
249+
Rs. 3,230.70
499+
Rs. 3,186.44
999+
Rs. 3,097.93
Share this product
Description
Description
|
Thrust Ball Thrust Bearings: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
Equivalent: F9-20G
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 9mm
- Outside Diameter:
- 20mm
- Width:
- 7mm
Technical
Technical
| d | 9mm |
|---|---|
| D | 20mm |
| H | 7mm |
| Dynamic load C | 3.12 kN |
| Static load Co | 3.8 kN |
| Fatigue load limit Pu | 0.143 kN |
| Minimum load factor A | 0.000075 |
| Reference speed | 12000 rpm |
| Limiting speed | 16000 rpm |
| Weight | 0.01 kg |
| d1 | 19.8mm |
| D1 | 9.2mm |
| r1r2 min | 0.3mm |
| da min | 15.5mm |
| Da max | 13.5mm |
| ra max | 0.3mm |
