SKU: 6314-2NSE/C3-NACHI
NACHI 63142NSEC3 Contact Rubber Sealed Deep Groove Ball Bearing 70x150x35mm
NACHI 63142NSEC3 Contact Rubber Sealed Deep Groove Ball Bearing 70x150x35mm
Regular price
Rs. 10,986.57
Regular price
Sale price
Rs. 10,986.57
Taxes included.
Equivalent to: 6314NSEC3 6314DUC3 6314RSC3 6314RSHC3 6314PC3 6314RSRC3 6314LUC3 6314DDUC3 63142RSC3 63142RS1C3 63142RSHC3 6314PPC3 63142RSRC3 6314LLUC3
In stock
Price Break
10+
Rs. 9,778.05
19+
Rs. 9,228.72
29+
Rs. 9,118.85
39+
Rs. 9,008.99
49+
Rs. 8,899.12
74+
Rs. 8,789.26
99+
Rs. 8,239.93
199+
Rs. 8,130.06
249+
Rs. 8,020.20
499+
Rs. 7,910.33
999+
Rs. 7,690.60
Description
Description
|
NACHI Contact Rubber Sealed Deep Groove Ball Bearings: These deep groove ball bearings can sustain radial, axial or composite loads and because of simple design, this bearing type can be produced to provide both high-running accuracy and high-speed operation. This bearing has two contact rubber seals in contact with inner ring. Benefits: High-running accuracy and high-speed operation, excellent grease sealing at low speeds, excellent protection against dust and water. |
Equivalent: 6314NSEC3 6314DUC3 6314RSC3 6314RSHC3 6314PC3 6314RSRC3 6314LUC3 6314DDUC3 63142RSC3 63142RS1C3 63142RSHC3 6314PPC3 63142RSRC3 6314LLUC3
- Brand / Quality:
- Nachi - High Quality
- Inside Diameter:
- 70mm
- Outside Diameter:
- 150mm
- Width:
- 35mm
- Seals / Shields:
- Rubber Sealed
- Clearance:
- C3
Technical
Technical
| Inside Diameter d | 70mm |
|---|---|
| Outside Diameter D | 150mm |
| Width B | 35mm |
| Min radius r | 2.1mm |
| Dynamic load | 104000 kN |
| Static load | 68000 kN |
| Max speed | 4600 rpm |
| da min | 82mm |
| Da max | 138mm |
| ra max | 2mm |
| Weight | 2.52 kg |
