SKU: 6305ZZC3-NSK
NSK 6305ZZC3 Metal Shielded Deep Groove Ball Bearing 25x62x17mm
Equivalent to: 6305ZZEC3 63052ZC3 6305.2ZC3 63052ZRC3 6305FFC3
In stock
Price Break
Description
Metal Shielded Deep Groove Ball Bearings: One of the most commonly used bearings, these types are manufactured with metal shields inserted into the outer raceway, these fit in closely to the inner race providing protection against light mechanical damage, some protection against the ingress of moisture, dust and other foreign matter and serve to retain the pre-filled grease in the bearing.
Shields can be removed for applications that don't require a shield or only require 1 shield.
Benefits: Provides light mechanical protection, limits moisture and dirt ingress, lubricated for life, cost-effective solution.
Equivalent: 6305ZZEC3 63052ZC3 6305.2ZC3 63052ZRC3 6305FFC3
- Brand / Quality:
- NSK - High Quality
- Inside Diameter:
- 25mm
- Outside Diameter:
- 62mm
- Width:
- 17mm
- Seals / Shields:
- Metal Shielded
- Clearance:
- C3
Technical
| d | 25mm |
|---|---|
| D | 62mm |
| B | 17mm |
| r min | 1.1mm |
| Dynamic load Cr | 20600 N (2100 kgf) |
| Static load Cor | 11200 N (1150 kgf) |
| Factor | 13.2 |
| Speed in grease | 11000 rpm |
| Speed in oil | 13000 rpm |
| Weight | 0.235 kg |
