SKU: 5309-ZZ-KSM
KSM 5309ZZ Metal Shielded Double Row Angular Contact Ball Bearing 45x100x39.7mm
KSM 5309ZZ Metal Shielded Double Row Angular Contact Ball Bearing 45x100x39.7mm
Regular price
Rs. 8,424.92
Regular price
Sale price
Rs. 8,424.92
Taxes included.
Equivalent to: 3309ZZ
In stock
Price Break
10+
Rs. 7,498.18
19+
Rs. 7,076.93
29+
Rs. 6,992.68
39+
Rs. 6,908.43
49+
Rs. 6,824.19
74+
Rs. 6,739.94
99+
Rs. 6,318.69
199+
Rs. 6,234.44
249+
Rs. 6,150.19
499+
Rs. 6,065.94
999+
Rs. 5,897.44
Share this product
Description
Description
|
Metal Shielded Double Row Angular Contact Ball Bearings: Correspond to the design of two single row angular contact ball bearings side by side but occupying less space. They can accommodate radial loads as well as axial loads acting in both directions. They provide a rigid bearing arrangement and accommodate tilting moments well. Benefits: Compact, rigid, accommodates tilting, radial and axial loads |
Equivalent: 3309ZZ
- Brand / Quality:
- KSM - Good Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 100mm
- Width:
- 39.7mm
- Seals / Shields:
- Metal Shielded
Technical
Technical
| --- | Bearing Dimensions |
|---|---|
| d | 45mm |
| D | 100mm |
| B | 39.7mm |
| --- | Abutment Dimensions |
| a | 60mm |
| r1r2 min | 1.5mm |
| r1r2 max | 1.5mm |
| Da min | 53.5mm |
| da max | 91.5mm |
| --- | Speeds, Weights and Loads |
| Basic Load Raiting Dynamic Cr | 72500 N |
| Basic Static Load Raiting Cor | 54000 N |
| Limiting Speed in Grease | 1000 rpm |
| Limiting Speed in Oil | 5300 rpm |
| Weight | 1.34 kg |
