SKU: 30MM-BTU
Major Brand 8003013 Heavy Duty Ball Transfer Unit - 30mm
Major Brand 8003013 Heavy Duty Ball Transfer Unit - 30mm
Regular price
Rs. 3,016.12
Regular price
Sale price
Rs. 3,016.12
Taxes included.
In stock
Price Break
10+
Rs. 2,684.35
19+
Rs. 2,533.54
29+
Rs. 2,503.38
39+
Rs. 2,473.22
49+
Rs. 2,443.06
74+
Rs. 2,412.90
99+
Rs. 2,262.09
199+
Rs. 2,231.93
249+
Rs. 2,201.77
499+
Rs. 2,171.61
999+
Rs. 2,111.28
Description
Description
Heavy Duty 800 Series Ball Transfer Units: The body and outer ring are manufactured from Zinc Plated Carbon Steel. On the base of the unit there is a dirt hole which aims to reduce potential contaminents which improves efficiency and allows smoother running. These ball transfer units have a maximum dynamic load capactiy of upto 350kg (ball up) and 175kg (ball down). The maximum operating temperature is 70 deg C (continuous) or 100 deg C (intermittent).
- Brand / Quality:
- Major Brand - High Quality
- Outside Diameter:
- 30mm
- Width:
- 36.8mm
Technical
Technical
| Ball Diameter | 30mm |
|---|---|
| Dirt Hole Diameter | 2mm |
| Amount of Exposed Ball | 5.5mm |
| D | 54.5mm |
| D1 | 45mm |
| W | 36.8mm |
| W1 | 31.3mm |
| W2 | 13.8mm |
| F | 3.4mm |
| Weight | 0.362 kg |
