SKU: 24060-B-MB-C3-FAG
FAG 24060BMBC3 Spherical Roller Bearing with Cylindrical Bore 300x460x160mm
FAG 24060BMBC3 Spherical Roller Bearing with Cylindrical Bore 300x460x160mm
Regular price
Rs. 933,031.50
Regular price
Sale price
Rs. 933,031.50
Taxes included.
In stock
Price Break
10+
Rs. 830,398.04
19+
Rs. 783,746.46
29+
Rs. 774,416.15
39+
Rs. 765,085.83
49+
Rs. 755,755.52
74+
Rs. 746,425.20
99+
Rs. 699,773.63
199+
Rs. 690,443.31
249+
Rs. 681,113.00
499+
Rs. 671,782.68
999+
Rs. 653,122.05
Description
Description
|
Spherical Roller Bearings: These bearings have two rows of barrel shaped (spherical) rollers which run on a common spherical outer and inner raceway, they are inclined at an angle to the bearings axis. Their design offers many features such as self alignment, insensitivity to misalignment, tolerance to heavy radial and axial loads etc. They are manufactured with in both parallel and tapered bore variants. Benefits: High radial and axial loads, misalignment, taper and parallel bore options |
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 300mm
- Outside Diameter:
- 460mm
- Width:
- 160mm
- Seals / Shields:
- None
- Clearance:
- C3
Technical
Technical
| --- | Dimensions |
|---|---|
| d | 300mm |
| D | 460mm |
| B | 160mm |
| r min. | 4mm |
| D1 | 401.5mm |
| ds | 8mm |
| ns | 15mm |
| da min. | 314.6mm |
| Da max. | 445.4mm |
| ra max. | 3mm |
| --- | Loads, Speeds and Weights |
| Fatigue limit load | 300000 N |
| Limiting speed | 1000 rpm |
| Reference speed | 700 rpm |
| Dynamic Load Rating | 2500000 N |
| Static Load Rating | 5200000 N |
| Mass | 102kg |
| --- | Factors |
| e | 0.35 |
| Y1 | 1.95 |
| Y2 | 2.9 |
| Y0 | 1.91 |
