SKU: 20B-2-SYNO-10FT-RENOLD
Renold SYNO 20B-2 BS Duplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
Renold SYNO 20B-2 BS Duplex Roller Chain 1-1/4 inch Pitch - 10 Feet Length
Regular price
Rs. 370,542.80
ex VAT
Regular price
Sale price
Rs. 370,542.80
ex VAT
Equivalent to: SNX20B-2
In stock
Price Break
10+
Rs. 329,783.09
19+
Rs. 311,255.95
29+
Rs. 307,550.52
39+
Rs. 303,845.10
49+
Rs. 300,139.67
74+
Rs. 296,434.24
99+
Rs. 277,907.10
199+
Rs. 274,201.67
249+
Rs. 270,496.24
499+
Rs. 266,790.82
999+
Rs. 259,379.96
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Duplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX20B-2
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 31.75mm = 1.25 (1-1/4) inch
Technical
Technical
| Pitch (A) | 1.25 inch |
|---|---|
| Pitch (A) | 31.75mm |
| Inside Width min (B) | 19.56mm |
| Roller Diameter max (C) | 19.05mm |
| Plate Height max (D) | 26.42mm |
| Plate Width Inner max (E) | 4.62mm |
| Plate Width Outer max (F) | 3.61mm |
| Pin Diameter max (G) | 10.19mm |
| Pin Length max (H2) | 76.7mm |
| Connecting link extension max (J) | 2.7mm |
| Transverse Pitch nom (K) | 36.45mm |
| ISO606 Tensile strength min | 170000 N |
| Weight | 7.8 kg/m |
