SKU: 20312-TVP-MB
20312TVP Barrel Roller Bearing with Cylindrical Bore 60x130x31mm - Allow 2-3 Days
20312TVP Barrel Roller Bearing with Cylindrical Bore 60x130x31mm - Allow 2-3 Days
Regular price
Rs. 32,870.10
Regular price
Sale price
Rs. 32,870.10
Taxes included.
In stock
Price Break
10+
Rs. 29,254.39
19+
Rs. 27,610.88
29+
Rs. 27,282.18
39+
Rs. 26,953.48
49+
Rs. 26,624.78
74+
Rs. 26,296.08
99+
Rs. 24,652.58
199+
Rs. 24,323.87
249+
Rs. 23,995.17
499+
Rs. 23,666.47
999+
Rs. 23,009.07
Description
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a cylindrical bore and a solid window cage made from glass fibre reinforced polyamide. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures up to +120 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 60mm
- Outside Diameter:
- 130mm
- Width:
- 31mm
- Clearance:
- * Standard
Technical
Technical
| d | 60mm |
|---|---|
| D | 130mm |
| B | 31mm |
| r min | 2.1mm |
| D1 | 111.2mm |
| da min | 72mm |
| Da max | 118mm |
| ra max | 2.1mm |
| Dynamic Load Cr | 146000 N |
| Static Load C0r | 170000 N |
| Fatigue limit load Cur | 15200 N |
| Limiting speed nG | 2800 rpm |
| Weight | 1.92 kg |
