SKU: 20207-K-TVP-C3-MB
20207KTVPC3 Barrel Roller Bearing with Taper Bore 35x72x17mm - Allow 2-3 Days
20207KTVPC3 Barrel Roller Bearing with Taper Bore 35x72x17mm - Allow 2-3 Days
Regular price
Rs. 15,778.31
Regular price
Sale price
Rs. 15,778.31
Taxes included.
In stock
Price Break
10+
Rs. 14,042.70
19+
Rs. 13,253.78
29+
Rs. 13,096.00
39+
Rs. 12,938.21
49+
Rs. 12,780.43
74+
Rs. 12,622.65
99+
Rs. 11,833.73
199+
Rs. 11,675.95
249+
Rs. 11,518.17
499+
Rs. 11,360.38
999+
Rs. 11,044.82
Description
Description
|
Barrel Roller Bearings: These bearings are single row, self aligning roller bearings. They consist of solid outer rings with a concave raceway, solid inner rings with two ribs and barrel rollers with cages. This bearing has a tapered bore and a solid window cage made from glass fibre reinforced polyamide. The bearings can be lubricated from the end faces using oil or grease. Suitable for operating temperatures up to +120 deg C. Benefits: Suitable where high radial shock type loads occur and where misalignments up to 4 degrees must be compensated. |
- Brand / Quality:
- Major Brand - High Quality
- Inside Diameter:
- 35mm
- Outside Diameter:
- 72mm
- Width:
- 17mm
- Clearance:
- C3
Technical
Technical
| d | 35mm |
|---|---|
| D | 72mm |
| B | 17mm |
| r min | 1.1mm |
| D1 | 62.3mm |
| da min | 42mm |
| Da max | 65mm |
| ra max | 1mm |
| Dynamic load Cr | 40500 N |
| Static load C0r | 43000 N |
| Fatigue limit load Cur | 4900 N |
| Limiting speed nG | 4800 rpm |
| Weight | 0.296 kg |
