SKU: 100AT5/920
100AT5/920 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 184 Teeth
100AT5/920 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 184 Teeth
Regular price
Rs. 20,360.10
Regular price
Sale price
Rs. 20,360.10
Taxes included.
In stock
Price Break
10+
Rs. 18,120.49
19+
Rs. 17,102.48
29+
Rs. 16,898.88
39+
Rs. 16,695.28
49+
Rs. 16,491.68
74+
Rs. 16,288.08
99+
Rs. 15,270.08
199+
Rs. 15,066.47
249+
Rs. 14,862.87
499+
Rs. 14,659.27
999+
Rs. 14,252.07
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 1.5mm
- Belt Width Approx:
- 100mm
- Belt Length Approx:
- 920mm
- Number of Teeth:
- 184
- Item Type:
- AT5 Standard Timing Belt
Technical
Technical
| No of Teeth | 184 |
|---|---|
| Belt Width | 100mm |
| Belt Pitch | 5mm (AT5) |
| Belt Length | 920mm |
| Belt Thickness (hs) | 1.5mm |
| Tooth Height (ht) | 1.2mm |
| Tooth Pitch (t) | 5mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 8610 N |
| Belt Weight (per metre) | 0.34kg |
