SKU: 100AT5/620
100AT5/620 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 124 Teeth
100AT5/620 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 124 Teeth
Regular price
Rs. 16,659.08
Regular price
Sale price
Rs. 16,659.08
Taxes included.
In stock
Price Break
10+
Rs. 14,826.58
19+
Rs. 13,993.63
29+
Rs. 13,827.04
39+
Rs. 13,660.45
49+
Rs. 13,493.85
74+
Rs. 13,327.26
99+
Rs. 12,494.31
199+
Rs. 12,327.72
249+
Rs. 12,161.13
499+
Rs. 11,994.54
999+
Rs. 11,661.36
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 1.5mm
- Belt Width Approx:
- 100mm
- Belt Length Approx:
- 620mm
- Number of Teeth:
- 124
- Item Type:
- AT5 Standard Timing Belt
Technical
Technical
| No of Teeth | 124 |
|---|---|
| Belt Width | 100mm |
| Belt Pitch | 5mm (AT5) |
| Belt Length | 620mm |
| Belt Thickness (hs) | 1.5mm |
| Tooth Height (ht) | 1.2mm |
| Tooth Pitch (t) | 5mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 8610 N |
| Belt Weight (per metre) | 0.34kg |
