100AT5/545 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 109 Teeth
100AT5/545 ContiTech Standard Synchroflex Timing Belt 100mm Width 5mm Pitch 109 Teeth
Regular price
Rs. 14,601.82
Regular price
Sale price
Rs. 14,601.82
Taxes included.
In stock
Price Break
10+
Rs. 12,995.62
19+
Rs. 12,265.53
29+
Rs. 12,119.51
39+
Rs. 11,973.49
49+
Rs. 11,827.47
74+
Rs. 11,681.46
99+
Rs. 10,951.37
199+
Rs. 10,805.35
249+
Rs. 10,659.33
499+
Rs. 10,513.31
999+
Rs. 10,221.27
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 1.5mm
- Belt Width Approx:
- 100mm
- Belt Length Approx:
- 545mm
- Number of Teeth:
- 109
- Item Type:
- AT5 Standard Timing Belt
Technical
Technical
| No of Teeth | 109 |
|---|---|
| Belt Width | 100mm |
| Belt Pitch | 5mm (AT5) |
| Belt Length | 545mm |
| Belt Thickness (hs) | 1.5mm |
| Tooth Height (ht) | 1.2mm |
| Tooth Pitch (t) | 5mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 8610 N |
| Belt Weight (per metre) | 0.34kg |
