SKU: 100AT10/1360
100AT10/1360 ContiTech Standard Synchroflex Timing Belt 100mm Width 10mm Pitch 136 Teeth
100AT10/1360 ContiTech Standard Synchroflex Timing Belt 100mm Width 10mm Pitch 136 Teeth
Regular price
Rs. 37,375.08
Regular price
Sale price
Rs. 37,375.08
Taxes included.
In stock
Price Break
10+
Rs. 33,263.82
19+
Rs. 31,395.07
29+
Rs. 31,021.32
39+
Rs. 30,647.57
49+
Rs. 30,273.81
74+
Rs. 29,900.06
99+
Rs. 28,031.31
199+
Rs. 27,657.56
249+
Rs. 27,283.81
499+
Rs. 26,910.06
999+
Rs. 26,162.56
Description
Description
AT Standard SYNCHROFLEX® Timing Belts: This belt is manufactured by ContiTech, specialists in rubber and plastics technology. This Synchroflex belt is a truly endless belt, suitable for AT pulleys.
Standard Synchroflex belts consist of just two components, a wear-resistant Contilan carcass and high-grade endless steel wire tension members. This construction provides high flank load capacity and low elastic elongation which makes them unsurpassed for quality and accuracy.
Benefits: High power AT profile, low elastic elongation and high flank load capacity.
- Brand / Quality:
- ContiTech - High Quality
- Thickness:
- 2.5mm
- Belt Width Approx:
- 100mm
- Belt Length Approx:
- 1360mm
- Number of Teeth:
- 136
- Item Type:
- AT10 Standard Timing Belt
Technical
Technical
| No of Teeth | 136 |
|---|---|
| Belt Width | 100mm |
| Belt Pitch | 10mm (AT10) |
| Belt Length | 1360mm |
| Belt Thickness (hs) | 2.5mm |
| Tooth Height (ht) | 2.5mm |
| Tooth Pitch (t) | 10mm |
| Flank Angle (f) | 50 deg |
| Tension Member Loadings | 16000 N |
| Belt Weight (per metre) | 0.63kg |
