SKU: 06B-2-SYNO-10FT-RENOLD
Renold SYNO 06B-2 BS Duplex Roller Chain 3/8 inch Pitch - 10 Feet Length
Renold SYNO 06B-2 BS Duplex Roller Chain 3/8 inch Pitch - 10 Feet Length
Regular price
Rs. 100,082.90
ex VAT
Regular price
Sale price
Rs. 100,082.90
ex VAT
Equivalent to: SNX06B-2
In stock
Price Break
10+
Rs. 89,073.78
19+
Rs. 84,069.64
29+
Rs. 83,068.81
39+
Rs. 82,067.98
49+
Rs. 81,067.15
74+
Rs. 80,066.32
99+
Rs. 75,062.18
199+
Rs. 74,061.35
249+
Rs. 73,060.52
499+
Rs. 72,059.69
999+
Rs. 70,058.03
Couldn't load pickup availability
Description
Description
Renold SYNO Maintenace-free Corrosion-resistant Duplex Chain: Renold Syno Nickel Plated chain is ideal for situations where lubricant is to be avoided. Particularly in hygiene-sensitive applications. With a food industry-approved lubricant contained within its sintered bush, this chain needs no relubricating in practically every environment. The roller coating, unique to Renold, is especially suited to the food industry.
Equivalent: SNX06B-2
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 9.53mm = 0.375 (3/8) inch
Technical
Technical
| Pitch (A) | 0.375 inch |
|---|---|
| Pitch (A) | 9.525mm |
| Inside Width min (B) | 5.72mm |
| Roller Diameter max (C) | 6.35mm |
| Plate Height max (D) | 8.2mm |
| Plate Width Inner max (E) | 1.29mm |
| Plate Width Outer max (F) | 1.04mm |
| Pin Diameter max (G) | 3.28mm |
| Pin Length max (H2) | 23mm |
| Connecting link extension max (J) | 1.3mm |
| Transverse Pitch nom (K) | 10.24mm |
| ISO606 Tensile strength min | 16900 N |
| Weight | 0.77 kg/m |
